Parameter |
Specification |
|---|---|
|
Product Model |
YF-DN32-T |
|
Working Voltage Range |
5-24VDC |
|
Maximum Working Current |
15mA (DC5V) |
|
Load Capacity |
≤10mA (DC5V) |
|
Allowable Pressure |
≤0.4MPa |
|
Storage Temperature/Humidity |
-25~+80°C / 25%~90%RH |
|
Flow Range |
3-50L/MIN ±1% |
|
Pulse Characteristics |
(Hz)=[1.8*Q]±5% (108 pulses/liter) |
|
Inner Diameter/Outer Diameter |
Inlet: 32.5mm, Outlet: 30mm / 41.5mm |
|
Thread Length |
16mm |
|
Output Pulse High-level Voltage |
>4.5V (at 5VDC input) |
|
Output Pulse Low-level Voltage |
<0.5V (at 5VDC input) |
|
Output Pulse Duty Cycle |
50±10% |
|
Material |
SUS304 Stainless Steel Valve Body |
Application Range
Water flow sensors are mainly used in the following fields and equipment:
Gas water heaters, Electric water heaters, Washing machines, Wall-hung boilers,
Water vending machines, Electromagnetic water heaters, Water control (integrated) machines,
Water control devices,Heat pump hot water projects, One-card management systems,
Campus card water vending systems, Self-service water vending (selling) machines,
Water treatment equipment, Water and medicine distribution equipment, Cooling systems,
Circulation systems, Intelligent mechanical equipment, Heating equipment, Instruments and meters,
Pharmaceutical (preparation) equipment, Smart water meters, IC water meters.
