Item |
Specification |
|---|---|
|
Model |
OF06ZAT |
|
Thread / Port Size |
¾" BSP (G ¾") |
|
Output Frequency |
F = 1.2 × Q (Q in L/min) → 72 pulses per litre |
|
Hose Inside Ø / Outside Ø |
16 mm / 26 mm |
|
Thread Length |
18.7 mm |
|
Body Material |
PPS (Polyphenylene sulfide) |
|
Supply Voltage |
3.5 – 24 V DC |
|
Current Consumption |
≤ 10 mA (@ 5 V DC) |
|
Flow Range |
30 – 3 000 L/h |
|
Operating Temperature |
0 – 80 °C |
|
Operating Humidity |
35 % – 90 % RH (non-condensing) |
|
Max. Allowable Pressure |
≤ 1.2 MPa (≈ 12 bar) |
|
Storage Temperature |
–25 °C – +80 °C |
|
Storage Humidity |
25 % – 95 % RH |
|
Compatible Media |
Non-corrosive, low-viscosity liquids |
|
Accuracy (water) |
±1 % (within 30 – 3000 L/h) |
Application Range
Water flow sensors are mainly used in the following fields and equipment:
Gas water heaters, Electric water heaters, Washing machines, Wall-hung boilers,
Water vending machines, Electromagnetic water heaters, Water control (integrated) machines,
Water control devices,Heat pump hot water projects, One-card management systems,
Campus card water vending systems, Self-service water vending (selling) machines,
Water treatment equipment, Water and medicine distribution equipment, Cooling systems,
Circulation systems, Intelligent mechanical equipment, Heating equipment, Instruments and meters,
Pharmaceutical (preparation) equipment, Smart water meters, IC water meters.
