【Model No.】 ZJMAZ-25 BRASS
【Material】 Nylon + Brass
【Inlet & Outlet Diameter】 G1'' Female Male
【Power Supply】 3.5 - 24Vdc
【Working Current】 Max 15mA
【Output Pulse High Level】 > DC4.7V (input 5vdc)
【Output Pulse Low Level】 < DC0.5V (input 5vdc)
【Working Temperature】 -10°C ~ 70°C
【Flow Rate】 2 - 60L/min
【Frequency (Hz)】 1.8
【NPN Pulses】 About 108P/L
【Error】 +/- 5%
【Max Pressure】 1.0Mpa
【Cable / Connector】 3P-1000mm bare wires with tinned ends
【Wire Connection】 RED - vcc, BLACK - gnd, YELLOW - signal
Application Range
Water flow sensors are mainly used in the following fields and equipment:
Gas water heaters, Electric water heaters, Washing machines, Wall-hung boilers,
Water vending machines, Electromagnetic water heaters, Water control (integrated) machines,
Water control devices,Heat pump hot water projects, One-card management systems,
Campus card water vending systems, Self-service water vending (selling) machines,
Water treatment equipment, Water and medicine distribution equipment, Cooling systems,
Circulation systems, Intelligent mechanical equipment, Heating equipment, Instruments and meters,
Pharmaceutical (preparation) equipment, Smart water meters, IC water meters.
