OFZAT-06T G3/4" Brass Oval Gear Flow Sensor

1. 1.

   ​Model: OFZAT-06T

2. 2.

   ​Connection Size: 3/4" (G3/4 Thread)

3. 3.

   ​Operating Voltage: DC 3.5 to 24V

4. 4.

   ​Pipe Inner Diameter: 24.5mm

5. 5.

   ​Material: Brass

6. 6.

   ​Flow Range: 30 to 3000 L/h (Accuracy within ±2%)

7. 7.

   ​Pulse Frequency: (Hz) = [1.2 * Q] ±5% (Q: Flow in L/min). Equals 72 pulses per liter.

8. 8.

   ​Maximum Pressure Resistance: ≤ 1.0 MPa

9. 9.

   ​Output High Level: > DC 4.5V (at DC 5V Input)

10. 10.

    ​Output Low Level: < DC 0.5V (at DC 5V Input)

11. 11.

    ​Output Duty Cycle: 50% ±10%

12. 12.

    ​Max. Operating Current: 15mA (at DC 5V)

Application Range

Water flow sensors are mainly used in the following fields and equipment:

Gas water heaters, Electric water heaters, Washing machines, Wall-hung boilers,

Water vending machines, Electromagnetic water heaters, Water control (integrated) machines,

Water control devices,Heat pump hot water projects, One-card management systems,

Campus card water vending systems, Self-service water vending (selling) machines,

Water treatment equipment, Water and medicine distribution equipment, Cooling systems,

Circulation systems, Intelligent mechanical equipment, Heating equipment, Instruments and meters,

Pharmaceutical (preparation) equipment, Smart water meters, IC water meters.
